Super Slim 1000x500mm Cabinet Outdoor Full Color LED Signs for Event Concert Auditorium

Shenzhen Eachinled Optoelectronics Co.,Ltd
Contact Now
    Buy cheap Super Slim 1000x500mm Cabinet Outdoor Full Color LED Signs for Event Concert Auditorium from wholesalers

    Buy cheap Super Slim 1000x500mm Cabinet Outdoor Full Color LED Signs for Event Concert Auditorium from wholesalers
    • Buy cheap Super Slim 1000x500mm Cabinet Outdoor Full Color LED Signs for Event Concert Auditorium from wholesalers
    • Buy cheap Super Slim 1000x500mm Cabinet Outdoor Full Color LED Signs for Event Concert Auditorium from wholesalers
    • Buy cheap Super Slim 1000x500mm Cabinet Outdoor Full Color LED Signs for Event Concert Auditorium from wholesalers
    • Buy cheap Super Slim 1000x500mm Cabinet Outdoor Full Color LED Signs for Event Concert Auditorium from wholesalers
    • Buy cheap Super Slim 1000x500mm Cabinet Outdoor Full Color LED Signs for Event Concert Auditorium from wholesalers

    Super Slim 1000x500mm Cabinet Outdoor Full Color LED Signs for Event Concert Auditorium

    Ask Lasest Price
    Brand Name : Eachinled
    Model Number : P4.8 P5.2
    Certification : CE Rohs
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 5000 Square meters Per Month
    Delivery Time : 15 Days
    • Product Details
    • Company Profile

    Super Slim 1000x500mm Cabinet Outdoor Full Color LED Signs for Event Concert Auditorium

    Super Slim 1000x500mm Cabinet Outdoor Full Color LED Signs for Event Concert Auditorium


    1. CNC + Die Casting process cabinets

    The flatness of led panel surface is greatly improved by its CNC+Die Casting molding process (precision up to 0.05mm), thus it ensures the full screen’s seamless and precise installation.

    2. Super Slim
    The thickness is 80mm. This saves your installation space and packing size, it ensures the greatly fast movement and installation.

    3. Light Weight
    The weight of full panel is only 12KG, can be easily hanging up by one person, with only two person can finish 12sqm led screen installation in 30minutes, it saves your time and labor cost.

    4. Convenient and Fast Installation
    We adapted Plug and play designing for this series, the power and signal connector is quite easy and fast for in&out operation; and the signal connection can be in horizontal and vertical ways, it satisfied the rental application in any cases.


    Technical Specification:


    Pixel Pitch

    3.9mm

    4.8mm

    5.2mm

    LED type

    RGB 3in1 SMD2121

    RGB 3in1 SMD2121 RGB 3 in 1 SMD3528

    Pixel Density(dot/s.q.m)

    65536

    43402

    36864

    Resolution(WxH)

    256*128dot

    208*104 dot

    192*96

    Cabinet size

    1000x500x80mm

    Weight

    12kg

    12kg

    12kg

    Waterproof rate

    IP43

    Brightness

    1200nits

    1200nits

    1500nit

    View Distance

    3m

    4m

    5m

    Viewing Angle (H/V)

    140°/12

    Gray Scale

    16bit

    Color type

    68 Billion

    Max.Power Consumption

    250W/PCS

    120W/PCS

    110W/PCS

    Ave .Power Consumption

    130W/PCS

    60W/PCS

    45W/PCS

    Refresh rate

    1960Hz

    Gamma

    -5.0~+5.0

    Applied environment

    INDOOR/OUTDOOR

    Controller

    Synchronous display with control PC by DVI

    Support Input

    Composite ,S-Vide ,Component ,VGA,DVI,HDMI,HD_SDI

    Power input

    AC 110-220V±10%

    Environment

    temperature -10°C~+50°C,humidity 10~90% RH

    Operating Life

    50,000hour


    FAQ

    Q1: What's the pixel pitch for Indoor LED Display Screen ?

    A1: Indoor&Outdoor (3.9mm / 4.8mm/)

    Q2: Where is it used for?

    A2: Indoor & rental use. Widely used for backdrop of staging event, rental business, liveshow, concert, etc.


    Q3: Can it play HD video?

    A3: Yes, it can realize HD video function with Novastar controlling system.

    Q4: What's the controlling system?

    A4: Our standard controlling system for this model is Novastar. Also support other controlling system, like Linsn, etc.

    Q5: How about the size of project?

    A5: Please offer the size with "width by height" of project. We wil offer the suitable solution for your project size. I will appreciate it if any drawing files about installation offered.


    Our Service and Mission

    Eachinled has a perfect service system, including pre-sale service, in-sale service and after-sale service. To provide high quality service for our customers, we train every salesman with necessary product maintenance knowledge and organized a Technology Supporting Department with a group of excellent and professional engineers. Any problem you can contact us at any time you like.
    Pre-sale service:
    1. Reply enquiries in 24 hours.
    2. Market research and forecast for customer.
    3. Provide unique and professional solutions based on customer's requirement.
    4. Data sheet and samples offer.
    5. Other services, such as special packing design, factory visiting and so on.

    In-sale service:
    1. Tracking report in producing.
    2. Quality test report for every order.
    3. Photos and videos as per customer's requirement.
    4. Free spare parts.

    After-sale service:
    1. Lifetime free maintenance and upgrade.
    2. Complaint respond period not exceed 24 hours; maintenance guidance and problem solution supplied in 48 hours.
    3. Customer satisfaction tracking report.
    4. Free technician training.
    5. Full set of documents free of charge, which including installation guidance, software operation manual, easy maintenance manual and control system software CD and so on.
    6. Special service for big project, such as stadium, exhibitions, squares and so on.
