Indoor SMD2121 P3.91 Stage Led Video Panel with Light Weight Led
Cabinet
Description:
Lightweight. Convenient in transporting and installing & saving
labor cost, suitable for flow shows.
Nice appearance and simple structures.
P3.91 mm pitch 1 m x 0.5 m LED video panel equally suited for
installations and rentals. It runs on the Novastar control protocol
and is fully front & rear serviceable with easily accessed magnetic
LED modules. The panels may be mounted directly on a flat wall due
to the front-service option. The panel features powerful magnets in
the frame, which assist with hanging the panels
the one module size is 500mmx125mm, very easy to maintainence !
There is almost no more ribbon cables for the cabinet and module.
Everything connected straight on the PCB hub. Less cables means
less possible problems. And no need to disassemble the whole screen
for maintenance. Each component can be detached individually for
that purpose.
6.One button for both power and data signal
I-Series (small pixel pitch) Specification :
| Pixel Pitch | 3.9mm |
| Pixel Configuration | SMD2121 |
| Module Resolution | 128*32dots |
| Module Pixles | 4096dots |
| Module Size | 500*125mm |
| LED Cabinet Specification | |
| Cabinet Size(W*H*D) | 500*1000*70mm |
| Cabinet Resolution | 128*256dots |
| Module Quanity | 16pcs |
| Cabinet Pixels | 32768dots |
| Material | Die Casting Aluminum |
| Brightness | ≥1100cd/m2 |
| Pixel Density | 65536dots/m2 |
| Driving Method | 1/16 scan constant current |
| View Angle | 140H,120V |
| Optimal Viewing Distance | ≥3 |
| Brightness Control | Red,Green and Blue 4096 Grade/Each |
| Fresh requency | ≥2880Hz |
| Frame Frequency | 60Hz |
| Input Voltage | AC100 - 120V/50Hz |
| AC200 - 240V/50Hz |
| Defects Rate | ≤0.00001 |
| Power Consumption | Max:160W/Cabinet Average:80W/Cabinet |
| Screen weight | 12kg/Cabinet |
| MTBF | >10,000 hours |
| Life span | ≥100,000 hours |
| Earth Leakage Current | <3mA |
Product Photos:
Weight & Dimensions
Panel Dimensions: 500×500×100mm
Panel Weight: 8.8kg
Module Dimensions: 500×125mm
Flight case Package for led panels
Eachinled Exhibition in Germany
Looking for an indoor rental LED display for an event?
We provide LED screen solutions to take your event to the higher
level
LED display has been widely used in various industries, along with
the development of market economy, the application of LED display
will continue to expand.
You can tell us your project , we will make a suitable led screen
solution for you
Applications:
1.Indoor stage, TV studio, concert, theme park ,Stage Performance
,Live Events ,clubs, presentation ,concerts, festivals,exhibition ,
halls, shop windows or exhibitions ,conference ,Freestanding stage
backdrops and other places for advertising and entertaining
purposes.
Delivery
The goods is usually shipped by sea,take about one month
If you want to get the goods earlier,
also can be shipped by DHL, UPS, FedEx or TNT. It usually takes 4-8
days to arrive by air,
WHAT SIZE OF LED SCREEN CAN YOU PROVIDE?
LED screens are made up of panels of 500mm by 1000mm. Though screen
of any size could be made by adding panels together,
most common size screens are :
24 Panels 4.0m by 3.0m
40 Panels 5.0m by 4.0m
48 panels 6.0m by 4.0m
Choose an LED Screen with a pixel pitch (resolution) that suits
your need.Example :2.97mm 3.91mm. 4.81mm. 5.95mm
Service Content:
1. 24-hour hotline service, including counseling and technical
guidance.
2. On-line service.
3. Failure maintenance of LED panels.
4. Free professional technical training
5. Paid software upgrade.
6. Warranty service.
7. Engineering technical service.
Eachinled provide the perfect display solution for indoor events
such as exhibitions, conferences, awards shows, experimental
marketing and corporate events.
