P4mm High Brightness Showcase / Shopwindow Indoor LED Display
Screen Video Wall
Product Description:
1) With good lightening accordance and no mosaic.
2) Can play different formats of image files, flash, video signal
from TV, video and other equipments.
3) Different video frequency can be changed freely at the same
time, and the image can be enlarged and shrinked.
4) High brightness, and can be adjustable, meets the needs of
customer's requirements.
5) Uses real pixels rather than virtual pixcels, better viewing
effect .
6) With the best quality IC MBI5124, refresh rate can be reached
1920HZ, and show you the perfect visual effect.
7) The aluminum structure requires no fan. Combined with the noiseless
power supply, the cabinet is totally silent.
Technical Specifications:
| Small Pixel Outdoor LED Display |
| Module | Pixel Pitch | 4mm |
| Module size | 256mmx128mm |
| Density of pixel/(dots/m2) | 62500 |
| Led encapsulation | SMD2121 |
| Resolution of module | 64X32 dots |
| Main | Optimum viewing distance | 4m |
| View angle / ° | 140 H,140 V |
| Max power consumption/W/M2 | 800 |
| Size of cabinet/mm | 1024X1024 |
| Resolution of cabinet | 256x256 |
| Weight of cabinet/kg | 45 |
| Driving method | 1/8 scan constant current |
| Refresh rate Hz/S | ≥1920 |
| Luminance of white balance | ≥1400 nits |
| Waterproof rate | IP43(front)/ IP43(back) |
| Working vlotage | 110-220 VAC/+/- 10% |
| Input signal | RF,S-Video,RGB,RGBH,YUV,YC&Composition ,etc |
| Control system | Novastar(sending card,receiving cards and Hubs) |
| Average of non-failure life | >50,00h |
| Life span | >100,000h |
| Functionaless dot rate | <0.01% |
FAQ:
Q1: What is your products packing?
A1: We provide 3 kinds of packing case: carton paper case, plywood
packing case and flight packing case. Carton paper case for led
module. Wooden packing case for fixed installation cabinet. Flight
packing case for rental cabinet.
Q2: What about a cheaper price?
A2: As you know we are a factory, so the price we offer you is
reasonable, and we must make sure good quality. You can compare the
price to other suppliers if in all the same product, but if your
quantity is large indeed, we can also consider very less profit for
your long time cooperation with us to make co-win.
Q3: Can i visit your factory in China?
A3: Usually except our staff, other persons are not allowed to
visit the factory. As you know it is not good for workers to
produce intently. But, of course, our factory is open to our
customers, very welcome to visit us, and the person who is
responsible will guide you to scan the workshop every step, you
will know the rough producing situation, then you will be trustful
to us.
Q4: What is the pixel pitch?
A4: The pixel pitch is the distance between the centre of an LED
(or group of LEDs that make up a pixel) to the next adjacent LED.
The smaller this distance, the closer all the LEDs on the screen
are together and the better the resolution – meaning a more
detailed picture. So a lower pixel pitch number means a better
resolution than a higher pixel pitch number.
Q5: Do you provide onsite assistance?
A5: Yes, our trained professional is available during your event to
install, dismantle and support.
